3Racing Sakura 1/10 Scale FF 21 Kit

OVERVIEW
Advance FF21 the latest 1/10 on-road front-wheel-drive chassis frame from 3Racing! It is the latest front wheel frame from the trend going to mid-motor structure In 2020, that chassis running outstanding performance expected out the box, consistent all the way surrounding in the track, especial it running like a 4WD, acceleration without burn the front tires, cornering out more linear speed-up, front bumper raw material from copper with 43g for delivery more grip to the front, shortest belt as S3M225 for reducing power loss any time, all brand new designed component parts such as below:

1. New narrowed Gear diff adapt for the new bulkhead placed on the chassis frame
2. New Narrowed Bulkhead same as Advance 21M
3. Relocated the motor mount placed in the middle
4. Servo and Motor mount all in 1 designed with lightweight cutting
5. Front belt used as S3M225
6. Newly Motor mount and drive-train shaft, more lightweight
7. Bulkhead placed the stabilizer on downward keep the CG as lower
8. Gear diff comes with Metal bevel gears set
9. Front Diff. join used 4mm drive cushion
10. Shorted stabilizer ball Cap and 1mm offset stabilizer mount at the wishbone
11. Upper and Lower deck are premium grade carbon from US
12. Stabilizer Front n Rear is a new shape suitable for relocated
13. Double Steering Wiper style
14.Front Bumper made by Copper with 43g preload
15. All graphite battery mounting on FF21

SPECIFICATIONS
length:382mm
Width: 188mm
Height: 62mm
Wheelbase: 258mm
Frame: Graphite lower and upper
Drive system: Front Wheel Drive
Suspension: independent 4 wheel wishbone
Absorber : 44mm Big-bore filled absorber
Gear Ratio: 1.9:1

Require:
*540 size motor
*ESC
*7.4V LiPo hard case battery
*2 channels transmitter
*Steering servo
*Body

Information provided by 3Racing, subject to change without notice.
Photos show assembled kit for display purposes; item requires assembly and electronics.

3RACING Barcode: 4895124762059
